Jekyll - Continuous Deployment With Github, CircleCI, Kubernetes, and Google Cloud Platform - Part 2

Kubernetes logo

In Part 1, we integrated CircleCI with Github to trigger a build of our Jekyll website on each push to Github.

In this part, we will use Google Cloud Platform to achieve continuous deployment.

We will do so by adding two jobs to our CircleCI workflow.

The first job is containerisation which was mentioned in Part 1. As well as creating the Docker image, we will also upload it to Google Container Registry (cloud storage for Docker images).

The second job will handle the actual deployment to a production server. This will be done using Kubernetes.

Preliminary steps

Create a Gmail account
Login to Google Cloud
Create a project and enable billing
Install the Google Cloud SDK
Setup Google Container Registry (step 3 “Enable the API”)
Create a Kubernetes cluster in Google Cloud (Kubernetes Engine on the left hand side in Google Cloud Console)
Create a Google Cloud service account (“Creating a service account”)
Encode the contents of the JSON file downloaded in 7. cat path/to/json | base64 | tr -d "\n"
In CircleCI, Settings->Projects. Find the repository of your Jekyll website and click on the wheel icon in the top right hand corner. On the left hand side, Build Settings->Environment Variables, then Add Variable with name: GCLOUD_SERVICE_KEY, value: the encoded contents from 8.
Same as 9., add remaining environment variables in CircleCI:
- GCLOUD_PROJECT: <my-project>
- GCLOUD_COMPUTE_ZONE: <my-zone>
- GCLOUD_K8_CLUSTER: <my-cluster>
- DOCKER_CONTAINER_REGISTRY: <my-registry>

Optional (recommended) steps

To interact with the Kubernetes API on your local computer:

Check the Kubernetes command line tool is installed with kubectl version. If not, try gcloud components install kubectl, following any prompts
gcloud auth login
Point kubectl to the cluster created in 6.

gcloud container clusters get-credentials <my-cluster>

Add job - containerisation

Firstly, we have to modify our original build job so that the contents of _site are persisted and can be used by the next job.

version: 2
jobs:
  build:
    docker:
      - image: jekyll/jekyll:3.5.0
    working_directory: /srv/jekyll
    steps:
      - checkout
      - run:
          command: ./build-jekyll.sh
          environment:
            JEKYLL_ENV: production
      # additional step
      - persist_to_workspace:
          root: /srv/jekyll
          paths:
            - _site

Now that the contents of _site are persisted, we can create a new job in the workflow:

[bearing in mind that to push to Google Container Registry, we need to install and authenticate the Google Cloud SDK first]

  # add job `containerise`
  containerise:
    docker:
      - image: google/cloud-sdk:latest
    steps:
      - setup_remote_docker
      - checkout
      - attach_workspace:
          at: .
      - run:
          command: ./authenticate-gcloud.sh
      - run:
          command: docker build --tag "DOCKER_CONTAINER_REGISTRY"/"GCLOUD_PROJECT"/"<my-image>":"<my-image-version>" .
      - run:
          name: Push docker image
          command: docker push "DOCKER_CONTAINER_REGISTRY"/"GCLOUD_PROJECT"/"<my-image>":"<my-image-version>"
workflows:
  version: 2
  build-containerise:
    jobs:
      - build
      # add new job `containerise` to workflow
      - containerise:
          requires:
            - build
          filters:
            branches:
              only: master

with authenticate-gcloud.sh in the project root

#!/usr/bin/env bash

set -e

GCLOUD_SERVICE_KEY_PATH="$HOME"/gcloud-service-key.json
echo "$GCLOUD_SERVICE_KEY" | base64 --decode --ignore-garbage > "$GCLOUD_SERVICE_KEY_PATH"
gcloud auth activate-service-account --key-file="$GCLOUD_SERVICE_KEY_PATH"
gcloud config set project "$GCLOUD_PROJECT"
gcloud config set compute/zone "$GCLOUD_COMPUTE_ZONE"
gcloud auth configure-docker

As we want to expose our Jekyll site to the internet, we add EXPOSE 80 to our Dockerfile.

Add job - Kubernetes deployment

Deployment is done via kubectl which is part of the Google Cloud SDK.

Thus the changes to our CircleCI config.yml are quite similar to those above:

  # add job `deploy-production`
  deploy-production:
    docker:
      - image: google/cloud-sdk:latest
    steps:
      - checkout
      - run:
          commmand: ./authenticate-gcloud.sh
      - run:
          command: ./deploy.sh
workflows:
  version: 2
  build-containerise-deploy-production:
    jobs:
      - build
      - containerise:
          requires:
            - build
          filters:
            branches:
              only: master
      # add new job `deploy-production` to workflow
      - deploy-production:
          requires:
            - containerise
          filters:
            branches:
              only: master

However, as we will be interacting with the Kubernetes cluster, we add

gcloud container clusters get-credentials "<my-cluster>"

to authenticate-gcloud.sh.

The actual deployment happens in deploy.sh

#!/usr/bin/env bash

set -xe

kubectl apply -f deployment.yml
kubectl apply -f service.yml

Firstly, a Kubernetes deployment object is created as per deployment.yml

apiVersion: apps/v1beta2
kind: Deployment
metadata:
  name: my-deployment
spec:  # specification of desired behaviour of deployment
  selector:  # label selector for pods; must match pod template's labels
    matchLabels:
      app: my-app
  template:  # pod definition
    metadata:
      labels:
        app: my-app
    spec:  # specification of desired behaviour of pod
      containers:  # containers in pod
      - name: my-jekyll-nginx-container
        image: <my-registry>/<my-project>/<my-image>:<my-image-version>
        imagePullPolicy: Always
        ports:
        - containerPort: 80  # as per `EXPOSE 80` in Dockerfile

This however only makes our Jekyll site available within the Kubernetes cluster.

We want to make it also available externally at a static IP address.

Create an external static IP address in Google Cloud; in the console on the left hand side NETWORKING->VPC network->External IP addresses->RESERVE STATIC ADDRESS. Make a note of this IP address.

Secondly, create a Kubernetes service object as per service.yml

apiVersion: v1
kind: Service
metadata:
  name: my-service
spec:  # defines behaviour of service
  selector:  # route service traffic to pod(s) with label keys and values matching this selector
    app: my-app  # as per label for pod above
  type:  LoadBalancer  # determines how service is exposed
  loadBalancerIP: <my-static-ip>  # only applies to `type: LoadBalancer`; supported by Google Cloud
  ports:  # ports exposed by service
  - port: 8080  # exposed port
    targetPort: 80  # number or name of port to access on pod(s) targeted by service; matches `containerPort: 80` in deployment.yml

Before pushing these changes to Github, you can check the syntax of your Kubernetes YAML files:

kubectl apply --validate=true --dry-run=true --filename=<my-kubernetes-file>

If all goes well and your jobs build successfully in CircleCI, you should be able to view your site at <my-static-ip>:8080.

NB: This might take a few moments, you can check it is ready with kubectl get services (assuming you completed the optional steps).
